ChiefArchitect ©

ChiefArchitect © software features both conceptual design, as well as detailed architectual drawing output for building construction. Roof line generation is also semi - automatic. Three dimensional (3D) views allow unified design at the concept stage, facilitating "form to follow function".

Second Story of Vacation Cabin

Using the slope of the hill, an exterior deck surrounds the upper floor. Double glass sliding doors provide access to the deck and views of golf course in the vacation cabin. Furniture arrangement centered on the fireplace provides for evening relaxation. The Ground Floor and Roof is omitted for clarity.
